Ball valve 2 piece dry cleaned lock lever Stain.St./PTFE+Glass thread BSPT PN63
The shown images can differ from the actual product. Technical data & prices are subjected to be changed without prior notice.
BSP
PTFE
| Model: | 2 piece body | Material body: | Stainless steel EN 1.4408 |
| Connection: | Thread BSPT ISO 7/1 Rp | Material Ball: | Stainless steel EN 1.4408 |
| Pressure: | 63 bar | Material seat: | PTFE + 15% glass fiber |
| Temperature: | -20°C / 200°C | Operation: | Lever |
| Specifications: | For oxygen | Specifications: | Silicone free |
| ATEX Group II Category 2 G/2D Zone 1 & 21 Zone 2 &22 ( optional marking ) |
| Valve in accordance with the regulation EC 1935/2004 (on request) |
| Dry cleaned stainless steel ball valve for oxygen. |
Datasheet (PDF)
| SKU | MXT-7143022000 |
|---|
| Body material | StainlessSteel-1.4408-316. |
|---|---|
| Disc / Ball / Wedge | StainlessSteel-1.4408-316 |
| Seat | PTFE filled with 15% glass |
